Customized Dining Tralier Container Coffee Shop Mobile Container Unit

Name: China Customized Dining Tralier Container Coffee Shop Mobile Container Unit Exporter
Brand: Shanghai Xingfeng Color Board Light Steel Structure Co.,Ltd
Availability: InStock

The Customised Dining Trailer Container Coffee Shop Mobile Container Unit is a versatile and innovative solution for entrepreneurs looking to start their own coffee shop business. This mobile container unit is designed to be easily transported and set up in various locations, allowing coffee shop owners to reach a wider customer base and adapt to changing market demands.

Inquiry Basket

OEM：

Available

Sample：

Available

Payment：

L/C,T/T

Place of Origin：

China

Supply Ability：

20 set per Month

Product Details

Product Description

The Customised Dining Trailer Container Coffee Shop Mobile Container Unit is a fully customizable and self-contained coffee shop on wheels. It is built using a high-quality shipping container, which provides durability, security, and easy transportation. The container is modified to include all the necessary features and equipment required to run a successful coffee shop.

The Details of Product

Inclusions List

No.	Dining room	Area	30m2	Spec.	Main Body
Chassis	Meter
1	Name	Qty	Unit	Spec.	Remark
2	A/C	2	ea	2HP	Gree, split type, cooling
3	Emergency lamp	1	ea
4	Smoke detector (battery type)	1	ea	LX98A-D
5	Cloth-hook	2	ea
6	Curtain	3	ea	clothing
7	Service table	1	ea	s.s
8	Dining table	4	ea	Melamine board, S.S. legs
9	Bench seating	8	ea	folding chair
10	TV receiver rack	1	ea	steel and paint
11	Refrigerator	1	ea	429L	Haier
12	TV	1	ea	32"LCD	Sony
13	Mosquito killer	2	ea

14	Electric system		1		set
15	Water supply & drainage system		1		set
16	S/S sink and cabinet		1 set
1	Qty.	Unit	Name	Spec.		Remark
2	1	ea	Generator	Perkins: 403A-11G1		7kW/9kVA
No.	Dinning room	Area	30㎡	Spec.		Main body
3	2	ea	A/C	2HP ,split type,cooling and heating,high temperature
4	1	ea	Water tank	0.5m³ PE
5	2	ea	Fire extinguisher	3kg dry power
6	1	ea	Smoke detector
7	4	pcs	Dining table	4 seat -
8	8	ea	Bench
9	1	ea	Freezer	429L
10	1	ea	S.S water sink	with cabinet
11	1	ea	Pump
12	2	ea	Window curtain
13	1	ea	Coffee machine
14	1	ea	32'' TV	LED with reciver rack		Sony
15	2	ea	Exhaust fan
16	2	ea	Electrical mosquitio killer
17	Portiere	3	set
18	3	ea	Doormat
19	1	set	Electric system
20	1	set	Water supply & drainage system
Qty： 2 units

Product Features and Benefits

Dining Trailer Specification

Chassis

1. The chassis is 10m long and 3m wide.
2. The maximum bearing capacity is 20 tonnes.
3. A double pipeline brake with a link pipe system is used on these trailers. This kind of brake system is called a four-wheel brake when there is no gas.
4. There are steel nets beside the chassis with bumpers in the back. There are fenders for tyres.
5. The chassis includes double axles and four wheels.
6. The tyres are desert type, of Chinese origin.
7. There is a redirector for the chassis.
8. Each trailer has a spare tyre rack, and a single spare tyre is supplied per trailer.
9. There is an alarm light on the trailer.
10. The four supporting racks operated by hand are supplied when the trailer is used. The supporting racks can be raised during transportation.

Interior

1. 10 m long, 3m wide, and 2.440m high for ceiling height.

2. Floor: 2mm steel board fixed as a base on the chassis. 100-C steel channel joists with 100-mm-thick fibreglass insulation 5/8" plywood is fixed to the joists with a 2mm vinyl floor finish.

3. Roof: 2 mm steel board framed with 100 steel square tubes. 100 mm of fibreglass insulation between the joists The waterproof drywall is fixed to wooden joists.

4. Exterior wall: 2mm thick steel board as exterior structure board. 100 mm thick fibreglass between wood joists 3/8" OSB board is fixed to the wood joists. PVC-covered drywall is fixed to the OSB as the interior fishing.

Partition

2x4 stud @ 2’, both sides of the 3/8" OSB with 3/8" PVC covered
drywall.

Outside

The top and bottom are blue, and the main body is white.

Electrical and Lighting

1. Power： 220v， 380v/50hz.
2. The electrica- circuit is parallel connection.
3. There are sub electrical panels for rooms. There is a bconnectionseach circuit.
4. The TCL outlets for intersurface-ennekes for exterior connection.
5. Interior lighting typeslampsrfaced mouareas, and2-tube fluorescent lamp, ceiling
mounted lamps, damp proof lamp for damp area; water proof lamps at exterior
Plumbing 1rgency lamps are supplied.

Plumbing

The water supply is PE pipe, surface mounted. Exterior water pipe is aluminium pipe.

Mechanical

2 x A/C, Gree. 2 HP, cooling split type. Ventilation as shown. No hot water heater is provided.

Windows and Doors

Exterior doors are freezer door types with a door closer and a s/s door handle.
Deadlock panic bar hardware Interior colour: white.
Window: PVC frame, double-glazed glass with bug screens provided. Steel
cover is supplied.

Fixtures and Fittings

1. A fridgeble aTV are bench are fixed type.
2. Fridge and TV provided.
3. S/S sink and cabinet wsh area.
4. Service area bench top.
Others 1. A smoke detector (220 volt) is supplied.
